Zee Miniature Aluminum Extrusions
Our aluminum extrusion Zee dies are available for your use and can speed your project to completion. Mann Made has secondary process facilities including CNC mills, drills, and cut-off saws. Aluminum Zee extrusions can be cut to length or, cut and machined to client’s specifications. Complete parts can be finished as required.
Multiple alloys available include:
- 6063
- 2024
- 7075
- 6061
- 1100
- 3003
- 6463
- 6101
Ready to Get Started?
Let us partner with you to manufacture and fabricate quality precision extrusions. We offer a quick turn around on quotes.
Request a QuoteWedges Table
Die # | A | B | C | T1 | T2 | T3 | R | R1 | R2 | Wt./Ft. |
F-8729 | 0.150 | 1.280 | 1.120 | 0.050 | 0.060 | 0.153 | ||||
F-8266 | 0.186 | 0.312 | 0.500 | 0.062 | 0.065 | |||||
F-257 | 0.190 | 0.375 | 0.375 | 0.040 | – | – | – | 0.043 | ||
F-634 | 0.218 | 0.042 | 0.095 | 0.120 | 0.005 | |||||
F-749 | 0.237 | 0.375 | 0.375 | 0.050 | 0.053 | |||||
F-2281 | 0.248 | 0.605 | 0.700 | 0.030 | 0.015 | 0.053 | ||||
F-399 | 0.250 | 0.625 | 0.560 | 0.125 | 0.020 | 0.020 | 0.020 | 0.187 | ||
F-3138 | 0.257 | 0.500 | 0.750 | 0.032 | .010(2) | .026(2) | 0.057 | |||
F-2622 | 0.286 | 0.330 | 0.330 | 0.050 | 0.080 | 0.010 | 0.010 | 0.054 | ||
F-2186 | 0.286 | 0.330 | 0.300 | 0.050 | 0.080 | 0.055 | ||||
F-116 | 0.312 | 0.562 | 0.250 | 0.062 | 0.062 | 0.077 | ||||
F-3639 | 0.375 | 0.749 | 0.625 | 0.062 | 0.125 | .010(5) | .062(2) | 0.125 | ||
F-7109 | 0.375 | 0.375 | 0.375 | 0.045 | 0.056 | |||||
F-8546 | 0.382 | 1.000 | 0.938 | 0.062 | 0.062 | 0.030 | 0.030 | 0.173 | ||
F-6974 | 0.390 | 1.060 | 1.190 | 0.040 | 0.060 | 0.075 | 0.030 | 0.120 | 0.182 | |
F-751 | 0.425 | 0.375 | 0.250 | 0.050 | 0.057 | |||||
F-1554 | 0.440 | 0.380 | 0.200 | 0.080 | 0.050 | 0.015 | 0.089 | |||
F-5685 | 0.460 | 0.720 | 0.620 | 0.090 | 0.185 | |||||
F-752 | 0.487 | 0.375 | 0.250 | 0.050 | 0.061 | |||||
F-3538 | 0.500 | 0.375 | 0.625 | 0.050 | 0.094 | 0.094 | 0.088 | |||
F-6802 | 0.500 | 0.625 | 1.062 | 0.125 | 0.010 | 0.010 | 0.010 | 0.290 | ||
F-1498 | 0.500 | 0.750 | 0.750 | 0.078 | 0.125 | 0.078 | 0.010 | 0.178 | ||
F-1824 | 0.500 | 0.750 | 0.750 | 0.062 | 0.125 | 0.062 | 0.178 | |||
F-2518 | 0.500 | 0.750 | 0.750 | 0.078 | 0.125 | 0.078 | 0.010 | 0.178 | ||
F-3635 | 0.500 | 0.750 | 0.750 | 0.050 | 0.094 | 0.050 | 0.117 | |||
F-4623 | 0.560 | 0.625 | 0.625 | 0.090 | 0.176 | |||||
F-7545 | 0.563 | 0.625 | 0.625 | 0.125 | 0.234 | |||||
F-2986 | 0.587 | 0.750 | 0.750 | 0.187 | 0.090 | 0.426 | ||||
F-1293 | 0.596 | 0.741 | 0.900 | 0.156 | 0.360 | |||||
F-3307 | 0.625 | 0.750 | 0.750 | 0.050 | 0.094 | 0.094 | 0.125 | |||
F-4927 | 0.625 | 0.750 | 0.750 | 0.062 | 0.125 | 0.062 | 0.155 | |||
F-1525 | 0.625 | 1.000 | 1.000 | 0.078 | 0.125 | 0.078 | 0.236 | |||
F-247 | 0.637 | 0.718 | 1.062 | 0.125 | 0.093 | 0.031 | 0.300 | ? | ||
F-7668 | 0.660 | 0.588 | 0.387 | 0.125 | 0.200 | 0.275 | ||||
F-2551 | 0.675 | 0.500 | 0.250 | 0.050 | R5-.300 | 0.100 | 0.080 | |||
F-4621 | 0.685 | 0.625 | 0.625 | 0.090 | 0.189 | |||||
F-4155 | 0.687 | 1.000 | 0.562 | 0.062 | 0.158 | |||||
F-8522 | 0.750 | 0.525 | 0.300 | 0.438 | 0.200 | 0.055 | 0.357 | |||
F-2980 | 0.750 | 0.625 | 0.625 | 0.062 | .125(4) | 0.148 | ||||
F-575 | 0.750 | 0.750 | 0.750 | 0.125 | 0.300 | |||||
F-2814 | 0.750 | 0.750 | 0.750 | 0.062 | 0.125 | 0.125 | 0.167 | |||
F-6767 | 0.750 | 0.750 | 0.750 | 0.050 | 0.094 | 0.050 | 0.132 | |||
F-1139 | 0.750 | 1.000 | 0.562 | 0.125 | 0.310 | |||||
F-2961 | 0.750 | 1.120 | 0.560 | 0.125 | 0.327 | |||||
F-1286 | 0.843 | 0.562 | 0.501 | 0.063 | 0.063 | 0.139 | ||||
F-1581 | 0.843 | 0.501 | 1.000 | 0.063 | 0.063 | 0.169 | ||||
F-1582 | 0.843 | 0.501 | 1.750 | 0.063 | 0.063 | 0.224 | ||||
F-1517 | 0.875 | 0.750 | 0.750 | 0.078 | 0.125 | 0.125 | 0.194 | |||
F-4928 | 0.875 | 0.750 | 0.750 | 0.062 | 0.125 | 0.062 | 0.174 |
